P/N:BY-GPS-204,GPS Dielectric Antenna,gps patch antenna 20x20x4mm size pin mount

Model: BY-GPS-204

iDielectric Antenna
Center Frequency(MHz):1575.42±3
VSWR:1.5:1
Bandwidth(MHz):15 Min
Impedance(Ω):50
Peak Gain>4dBi Based on 7cm×7cm ground plane
Gain Coverage>-4dBi at –90°<0 <+90°(over 75% Volume)
Polarization:RHCP
Power Handling(W):1
iiMechanical
Weight(gram)<10
Size(mm):20×20×4
iiiEnvironmental
Working Temp:-40℃~+85℃
Storage Temp:-45℃~+90℃
Vibration:Sine sweep1g(0-p)10~50~10Hz each axis
Humidity:Humidity95%~100%RH
